> 제품소개 > 급유식압축기

동급최고의 토출량
전폐형,고효율 모터 사용
COUPLING 직결구동
수분트랩장착
압력조절 CONTROLER에서 버튼으로 쉽게조절
FF TYPE (냉동식 드라이어 내장형) 선택사양
max.working pressure Capacity FAD(1) Installed motor Noise level(2) Weight
  Pack Full Feature Pack/Full Feature     Pack FULL Feature
  bare(e) psig bare(e) psig l/s ㎥/min cfm kW hp dB(A) kg lb kg lb
* GA200-315 Twin
GA200 -100 7.4 107 7.15 104 586 35.1 1242 185 250 76 4957 10928 5357 11810
-125 9.1 132 8.85 128 532 32.0 1128 185 250 76 4957 10928 5357 11810
-150 10.8 157 10.55 153 483 29.0 1024 185 250 76 4957 10928 5357 11810
GA250 -100 7.4 107 7.15 104 683 41.0 1448 225 300 76 5057 11149 5457 12030
-125 9.1 132 8.85 128 620 37.1 1314 225 300 76 5057 11149 5457 12030
-150 10.8 157 10.55 153 569 34.1 1206 225 300 76 5057 11149 5457 12030
-200 13.8 200 13.55 196 477 28.6 1011 225 300 76 5057 11149 5457 12030
GA315 -100 7.4 107 7.15 104 777 46.5 1647 260 350 76 5257 11590 5657 12470
-125 9.1 132 8.85 128 707 42.3 1499 260 350 76 5257 11590 5657 12470
-150 10.8 157 10.55 153 660 39.5 1399 260 350 76 5257 11590 5657 12470
-200 13.8 200 13.55 196 555 33.2 1177 260 350 73 5257 11590 5657 12470
GA355 -100 7.4 107 - - 1032 62.1 2191 335 450 73 7760/7860 17110/17331 - -
-125 9.1 132 - - 940 56.5 1992 335 450 73 7760/7860 17110/17331 - -
-150 10.8 157 - - 831 49.9 1761 335 450 73 7760/7860 17110/17331 - -
-200 13.8 200 - - 692 41.6 1466 335 450 73 7760/7860 17110/17331 - -
GA400 -100 7.4 107 - - 1128 67.9 2394 372 500 74 8360/7960 18433/17551 - -
-125 9.1 132 - - 1042 62.6 2208 372 500 74 8360/7960 18433/17551 - -
-150 10.8 157 - - 935 56.2 1981 372 500 74 8360/7960 18433/17551 - -
-200 13.8 200 - - 784 47.1 1661 372 500 74 8360/7960 18433/17551 - -
GA450 -100 7.4 107 - - 1334 80.4 2835 447 600 75 8360/8620 18433/19007 - -
-125 9.1 132 - - 1222 73.4 2589 447 600 75 8360/8620 18433/19007 - -
-150 10.8 157 - - 1126 67.7 2386 447 600 75 8360/8620 18433/19007 - -
-200 13.8 200 - - 943 56.7 1998 447 600 75 8360/8620 18433/19007 - -
GA500 -100 7.4 107 - - 1518 91.2 3217 522 700 76 7960 17551 - -
-125 9.1 132 - - 1404 84.4 2975 522 700 76 7960 17551 - -
-150 10.8 157 - - 1296 77.9 2746 522 700 76 7960 17551 - -
-200 13.8 200 - - 1114 66.9 2361 522 700 76 7960 17551 - -
